GSAP ScrollTrigger + MotionPath Animation Product Website Tutorial HTML CSS JS

by

GSAP ScrollTrigger + MotionPath Animation Tutorial HTML CSS JS

GSAP ScrollTrigger + MotionPath Animation Tutorial HTML CSS JS

GSAP ScrollTrigger + MotionPath Animation Tutorial HTML CSS JS

bg (5)

Overview

This project is a premium skincare landing page that uses a combination of fixed and animate-on-scroll elements, along with smooth motion paths. By employing HTML + CSS + GSAP we created:



  • A floating jar with a skincare label
  • Hero text with plant images sliding out
  • Ingredient “cards” which slide along a curved SVG path
  • Features section with overlay reveal
  • Last clean showcase section

Through this project we achieved a luxurious, cinematic scrolling experience that meets our client’s expectations.

🧱 Step 1: HTML Structure Explanation

The HTML structure has five main layers.

A. The Fixed Jar Wrapper

<div class=”hero__jar-wrap”>
         <img class=”jar__lid”>
         <img class=”jar__body”>
</div>

Why is it fixed?

As GSAP animates the jar, it remains in the center of the screen with a fixed position the entire time it moves. This causes the lid and jar body to move independently and generate a floating effect.

B. Header

A transparent header that contains the logo and navigation links, which is located above the hero section.

<header class=”site-header”>…</header>

The header will blend into the top of the hero section due to its transparency.

C. Hero Section

The Hero Section will consist of:

  • A large title graphic for Freesias
  • There will be two images depicting plants (one on the left and one on the right).
  • Additionally, the Ingredients section contains a series of curved panels that will have a fixed position.

With this layout, I see a multi-layered cinematic experience being created.

D. Ingredient Card(s) plus SVG Curve

Ingredients Cards and SVG curves will reside in the Hero Section

<svg class=”curve-svg” viewbox=”0 0 200 100″>
         <path class=”curve-path” d=”M 5 5 A 100 100 0 0 0 205 5″ fill=”none” strock=”transparent”></path>
</svg>
Why this is essential:

  • The path is used by MotionPathPlugin

  • Each ingredient card travels along the curve

  • Smooth organic movement adds premium visual storytelling

E. Features Section

A Completely Oversized Section Above the Hero Section, which has:

margin-top: -100vh;

This allows the cream jar to appear to float over both the Hero Section and the Features Section.

Left side → text & feature items
Right side → large product cream image

Also includes a soft overlay + background image for depth.

F. Showcase Section

A “Clean” section for your viewer to take a moment to “rest” their eyes.

This Section will be displayed Full Screen with a Centered Layout.

🧱 Step 2: Why .hero__jar-wrap is Outside All Sections

The main purpose of the .hero__jar-wrap outside of any of the 3 main sections is 1 of the most important decisions for the overall architecture of this website.

Reason 1 — It must stay fixed

The jar can have movements through all 3 sections.

  • If the jar is located inside the HERO section, it would scroll away when the user scrolls down in the browser.
  • The jar animations don’t follow the GSAP Pinned Animation.
  • Any other movements that the jar would need to follow would be above or below any other layer.
Reason 2 — To animate globally

As the jar’s movements can happen through all 3 sections and they are all happening in different locations.

By putting .hero__jar-wrap outside of the sections, it will always be able to animate it globally.

Reason 3 — It’s visually layered above everything

The z-index of 1000 will provide the developer with full control over how all the layers stack.

This is a very common practice in creating GSAP websites.

🧱 Step 3: SVG Curve Path Explanation

The path:

M 5 5 A 100 100 0 0 0 205 5

M 5 5 A 100 100 0 0 0 205 5

Path Breakdown:



  • M 5 5 Move to the starting point
  • A 100 100 Draw an arc with a radius of 100
  • Inside 0 0 0: Arc flags (direction, rotation, and sweep)
  • 205 5 Ending point for the arc

The gentle curve is a great way to create smooth animation movements for each ingredient card.

GSAP maps the location of each ingredient card on this path using:

🧱 Step 3: Responsive Animated Navbar

The navigation bar for this project will consist of:

  • Logo
  • Search Icon
  • Cart Icon
  • Animated Hamburger Icon
  • Stagger Fade Navigation Items
HTML:

<nav class=”navbar”>
     <div class=”navbar__logo”>
          <img src=”logo.png” alt=”logo”>
     </div>

     <ul class=”navbar__menu” id=”navbar__menu-links”>
          <li class=”navbar__menu-item”><a href=”#”>Home</a></li>
          <li class=”navbar__menu-item”><a href=”#”>About</a></li>
          <li class=”navbar__menu-item”><a href=”#”>Hoodies</a></li>
          <li class=”navbar__menu-item”><a href=”#”>Collection</a></li>
          <li class=”navbar__menu-item”><a href=”#”>Contact</a></li>
    </ul>

CSS:

menuIcon.addEventListener(‘click’, () => {
     navLinks.classList.toggle(‘open’);



     if (navLinks.classList.contains(‘open’)) {
       menuIconChild.classList.replace(‘ri-menu-4-fill’,’ri-close-large-line’);



       menuItems.forEach((item, index) => {
             setTimeout(() => item.classList.add(‘show’), index * 100);
       });



     } else {
       menuIconChild.classList.replace(‘ri-close-large-line’,’ri-menu-4-fill’);
       menuItems.forEach(item => item.classList.remove(‘show’));
     }
});

When the user hovers over each item on the navigation bar, it will fade in with a smooth downward animation.

🧱 Step 4: Hero Section with a 3D Layered Textand a Beautiful Main Hoodie

The hero section contains:

  1. A very stylish handwritten cursive winter tagline,
  2. An extremely bold stretched HOODIE title,
  3. The main hoodie image,
  4. Perfect z-index at the right spot for layering, and
  5. Glassmorphism cards behind the main hoodie image.
HTML:

<div class=”hero__text”>
     <h4>Winter Special</h4>
     <h1>HOODIE</h1>
</div>

<div class=”hero__image”>
     <img src=”hoodie.png” alt=”hoodie”>
</div>

CSS:

.hero__text h1 {
    transform: scale(1, 1.5);
    letter-spacing: 5px;
}

The way the typography is laid out also gives off a high-end luxury feel to the hoodie.

🧱 Step 5: Floating Glassmorphism Info Panels

Behind the hoodie are two floating frosted information panels that list the following features:

  • Qualitiy of Material
  • Comfort Level
  • Durability
  • Quality Stitching
CSS:

.info__box {
    width: 650px;
    background: var(–glass-morphism);
    backdrop-filter: blur(20px);
    border-radius: 15px;
    border: 1px solid var(–primary-color);
    padding: 30px 60px;
    position: absolute;
}



.info__box.left { left: -1%; bottom: 30%; }
.info__box.right { right: -1%; top: 30%; }

A great way to present something new and classy!

🧱 Step 6: Footer with Contact, Order, and Social Media Icons

The footer contains:

  • A contact number
  • ORDER NOW button
  • Shopping cart icon
  • Glassmorphism social media icons
  • Hover interaction. HTML and Hover Glow Effects are used.
HTML:

<div class=”orderBox”>
    <div class=”orderIcon”><i class=”ri-shopping-cart-2-line”></i></div>
    <button class=”orderBtn”>ORDER NOW!</button>
</div>

Hover Glow Effect:

.orderBox:hover .orderIcon,
.orderBox:hover .orderBtn {
     border-color: #ffc800;
     transform: translateY(-2px);
}

This provides a premium winter look!

✨ Final Result - What you've built!

  • A high-end animated hoodie web page
  • Fully responsive mobile navigation systems
  • A glassmorphism hero section styled for winter
  • New extreme stretched HOODIE typeface
  • Two floating frosted informational boxes
  • A frosted nav bar with animations
  • A section for ordering and social media with neon flashes on hover.
  • Great for winter brands, clothing sellers, eCommerce stores, showcasing products, etc!
